Spring Antenna 824-960/1710-1990MHz

Spring Antenna with High Gain (3 dBi)

  • 50Ω
  • T2
  • 827~960MHz;1710~2170MHz
  • Phosphor bronze;Gold-plated
  • 1W
  • N/M
  • -40 ~ +85℃
  • 32*5mm
Quantity:

824-960/1710-1990MHz Spring Antenna with High Gain (3 dBi)


Antenna introduction:

824-960/1710-1990MHz FPC Antenna is in the 824-960/1710-1990MHz frequency band, and can be adjusted for 315/433/470/490/868/915/824-960/1710-1990MHz/GSM use, please contact us for more details, if you need to do any customization. The current connector uses SMA pure copper with gold-plated, with upmarket appearance, strong mechanical sense, and high gain 3dBi, while the daily output of this antenna can reach 5K sets. We can customize the packaging, antenna size, as well as design style according to your requirements, welcome to inquire!

The structure is simple, lightweight, wide frequency, high gain, and easy to install. Can be customized and designed according to your special needs.

For 315/433/470/490/868/915/824-960/1710-1990MHz/GSM

The copper foil of the FPC antenna usually uses electrolytic copper or rolled copper, and the thinner the overall thickness is, the less likely to lift. The backside adhesive has strong adhesive properties and high temperature resistance. They arewidely used in mobile phones, locomotives, Internet, artificial intelligence, smart home, smart city, intelligent agriculture,IoT industry and other fields.


Antenna characteristics:

● High gain

● Strong compati bility

● Good stability


Application field:

 Smart Express Cabinet

 Security alarm

 Smart buildings, smart buildings

 Smart home

 Power monitoring

 Smart Industry

 Traffic monitoring equipment

 Smart Agriculture

Temperature and humidity monitor

Drone

 Medical automation

 Wireless module


Electrical test report:

Frequency824-960/1710-1990MHz
Impedance50Ω
V.S.W.R≦1.4
Return loss135/46MHz
Gain3dBi
Linear polarizationvertical
Power1W
MaterialPhosphor bronze;Gold-plated
Operating temperature-10 ~ 70 ° C
Storage temperature-40 ~ +85℃
