Wireless module

DREAMLNK is Wireless module manufacturers and suppliers in China who can wholesale Wireless module. We can provide professional service and better price for you. If you interested in Wireless module products, please contact with us. Tips: Special needs, for example: OEM, ODM, customized according to demands, design and others, please email us and tell us detail needs. We follow the quality of rest assured that the price of conscience, dedicated service.
  • High-power ASR6601 LoRa Module with PA & TCXO (433/470Mhz)
    Model: DL-A6601PA-B
    Chip: ARS6601
    Frequency: 433MHz
    Voltage: 3.5~5.3V
    Distance: 6000m
    Size: 26*20.5*2.8mm
    This DL-A6601PA-B wireless transceiver module is a high-power RF module based on the ASR6601 chip solution with LoRa modulation, which integrates a 48MHz main frequency Cortex-M4 low-power core. While this ASR6601 SOC chip is an MCU with RF encapsulated, with higher integration than the SPI+MCU solution, but smaller size.
  • BLE 5.3 Module with TI's SimpleLink™ CC2340R5 Chip
    Model: DL-CC2340-B
    Chip: CC2340R5
    Frequency: BLE
    Voltage: 1.8~3.6V
    Distance: 70M
    Size: 26*20.5*3.5mm
    DL-CC2340-A and DL-CC2340-B BLE modules are both designed base on TI's SimpleLink™ wireless series CC2340R5 Bluetooth® Low Energy Chip, which uses a 48-MHz Cortex-M0+ kernel, integrates up to 512 KB of flash memory, 36 KB of SRAM,and has up to 26 universal I/O interfaces. Moreover, these Bluetooth Low Energy modules are equipped with a built-in 48MHz 10PPM external high-speed clock, and 32.768Khz external low-speed clock.
  • 433Mhz/868MHz/915MHz Wireless Transceiver Module with PAN3029 Chip
    Model: DL-PAN3029-S
    Chip: PAN3029
    Frequency: 433MHz/868MHz/915MHz
    Voltage: 2.0~3.6V
    Distance: 3000m
    Size: 17.1*16.1*2.5mm
    DL-PAN3029-S is a wireless module designed based on PANCHIP’s radio frequency chip PAN3029.The power supply of this module adopts a chip integrated DCDC working mode, which can greatly reduce power consumption in various modes. It is equipped with a built-in temperature compensation crystal, which can effectively reduce temperature drift and ensuring more stable transmission.
  • RFM95 868/915Mhz SX1276 Wireless Transceiver Modules
    Model: DL-RFM95
    Chip: SX1276
    Frequency: 868/915Mhz
    Voltage: 1.8~3.6 V
    Distance: 3000m
    Size: 16*16*3.9mm
    The 868/915Mhz RFM95 Wireless Transceiver Moduless feature the LoRa long range modem that provides ultra-long range spread spectrum communication and high interference immunity whilst minimising current consumption.
  • 868MHz/915MHz Transparent UART Transceiver Module with TI CC1310 Chip
    Model: DL-CC1310-B868 (915)
    Chip: CC1310
    Frequency: 868Mhz/915Mhz
    Voltage: 1.8~3.8V
    Distance: 800m
    Size: 18*16*2mm
    DL-CC1310-B Wireless Module is a SoC Transceiver Module (UART Module) with AT command, which was developed based on Texas Instruments' CC1310F128RHBR RF chip. It combines an integrated RF Controller (Cortex®-MO) and a powerful Arm® Cortex®-M3 Processor, which is ideal to use especially for battery power IoT applications.
  • 433Mhz Wireless Transparent SoC Transceiver Module TI CC1310 Chip
    Model: DL-CC1310-B433
    Chip: CC1310
    Frequency: 433Mhz
    Voltage: 1.8~3.8V
    Distance: 800m
    Size: 18*16*2mm
    This DL-CC1310-B Wireless Module supports Narrow-band Communication, Direct Sequence Spread Spectrum (DSSS), Long-range Transmission and High-efficiency Communication. Its fully functional AT Commands support any Serial Baud Rate setting from 1920bps to 256000bps, which can greatly improve the communication efficiency with up to -124dBm receiver sensitivity.
